Ammann Asphalt Mini Paver

The Ammann AFW150-2 1.2 ton 3-wheeled paver has a tight turning radius and clearance width make it ideal for paving footpaths and handling repair work in narrow surroundings

AFW150-2

The AFW150-2 is a unique machine that has no competitors on the market. The tight turning radius and clearance width make it ideal for paving footpaths and handling repair work in narrow surroundings. The paver is easy to transport and allows a fast set-up on the jobsite.

The AFW150-2 is a three wheel paver: two in the rear to enable traction and one in front for steering. The fixed hopper can be side-loaded with a skid steer.

The air-cooled diesel engine with electric start / stop is integrated with the hydraulic pumps. The hydrostatic transmission is engaged by a variable-flow pump that feeds two orbital motors fitted to the planetary drives of the wheels. A hydraulic control, mounted on the variable flow pump, enables smooth starts and stops. The paver also features hydraulic steering, easily controlled by the new steering wheel.

Specifications

Weight940 kg
Operating weight1260 kg
Machine width1150 mm
EngineHatz 1B50E

Features

  • C/w Vibration System
  • Gas Heating
  • Hydrostatic Drive
  • Hydraulic Extensions
  • Engine: Hatz model 1B40 6.3Kw Air Cooled
  • Greedy Hopper Extensions
  • Paving widths: 800mm – 1650mm
