Genie GS-3232 Electric Scissor Lift

Genie GS-3232 weighs 2352kg and is available with E-Drive at a max working height of 11.5M


The Genie® GS™-3232 E-Drive slab scissor lift is an electric model ideal for operation in emission and sound-sensitive indoor and outdoor jobsites where space is limited. The standard, state-of-the-art Genie AC electric E-Drive system offers unmatched efficiency and runtime on installation, maintenance and construction jobs, especially when a significant amount of driving is required.


Working heightIndoor: 11.50M / Outdoor: 7.49M
Lift capacity227kg / Extension deck extended: 113kg


  • Platform Height 9.78m
  • Steel platform 2.26 m x 0.81 m
  • 0.91 m (3 ft) extension deck
  • Folding rails with half-height swing gate
  • Automatic levelling outriggers
  • Dual front wheel drive
  • Proportional lift and drive
  • 30% gradeability
  • Platform control with battery chargeindicator and diagnostic display
  • Manual platform lowering valve
  • Emergency stop at both platformand ground controls
  • Rear wheel multiple disc brakes
  • Front wheel hydraulic dynamic braking
  • Manual brake release
  • Solid non-marking tyres
  • Pothole guards
  • Tilt alarm
  • Descent alarm
  • Electronic horn
  • Hour meter
  • Dual flashing beacons
  • Motion alarm
  • POWER- 24 V DC (four 6 V 225 Ah batteries)- Universal 20 amp smart charger
