U-110 Atlas Copco Silenced Diesel Compressor

The Atlas Copco U110 100 psi compressor is silenced, single stage and diesel powered, ideal for construction demands.

U110

This portable air compressor frame is rugged and built to last and designed for continuous use. It is great for building sites for laying foundations and ground consolidation and aslo pipeline cleaning due to its ability to vary pressure outputs. It is a drilling mobile diesel screw air compressor.

These compressors are designed to work in harsh conditions from -25 degrees – +50 degrees and a pre-heater option is available for the engine for use the colder conditions.

Specifications

Compressor TypeSilenced, Single Stage, Oil Injected Screw Compressor
Normal effective working pressurePsi 100
Compressor Air Delivery (FAD) cfm = 100 / 2.8 m3/min

Features

  • Full load RMP: 3600
  • Unload RPM: 2000
  • Fuel Tank: 30L
  • Stackable
  • Heavy duty coupling
  • Separator is equipped with high pressured sealed and certified safety relief valve.
  • Engine has a coolant cooler
  • Compresser is provided with an oil cooler
  • Engine model: Kubota D902 liquid cooled. three cylinder
  • Engine No. of cylinders 3
  • Engine Coolant Parcool
  • Length mm: 1580
  • Width *2 mm: 740
  • Height *2 mm: 850
  • Wet Weight KG: 488
  • 3 layers Zincor, Primer and Powder Coating
  • Low noise emissions: Sound Level 7mdB(A): 70
